Tuya Smart Deluxe Switch | 2 Light & 1 Curtain | Aluminum Frame | Spark Electric
Tuya Smart Deluxe Switch | 2 Light & 1 Curtain | Aluminum Frame | Spark Electric
Couldn't load pickup availability
Tuya Smart Deluxe Switch | 2 Light & 1 Curtain | Aluminum Frame | Spark Electric
✦ The Tuya Smart Deluxe Switch from Spark Electric is a premium wall switch designed to control Two lighting circuit and one motorized curtain from a single elegant panel, combining smart functionality with a luxury aluminum frame finish.
✦ Smart control is available anytime and from anywhere through the Smart Life or Tuya Smart mobile application, using a stable 2.4 GHz Wi-Fi connection without the need for an additional hub.
✦ Supports voice control via Amazon Alexa and Google Assistant, allowing hands-free operation for both lighting and curtain control using simple voice commands.
✦ Advanced scheduling and automation features let you create daily routines, scenes, and timers — such as opening curtains in the morning and turning lights off at night automatically.
✦ Dual control operation ensures flexibility, allowing manual touch control directly from the wall switch alongside smart app control without interference.
✦ Deluxe flat glass panel with an aluminum frame delivers a modern, high-end appearance suitable for smart homes, apartments, hotels, offices, and luxury residential projects.
✦ Designed for wide voltage compatibility and reliable performance, with stable operation when properly installed using a neutral wire.
✦ Ideal solution for users seeking a clean wall layout by combining lighting and curtain control into one smart switch.
Technical Specifications
| Specification | Details |
|---|---|
| Product Name | Tuya Smart Deluxe Switch – 2 Gang & 1 Curtain |
| Brand | Spark Electric |
| Control Channels | 2 × Light + 1 × Curtain Motor |
| Rated Voltage | AC 90–250V, 50/60Hz |
| Lighting Load | Up to 10A |
| Curtain Load | Motorized curtains (AC motor) |
| Wireless Standard | Wi-Fi 2.4GHz (802.11 b/g/n) |
| App Support | Smart Life / Tuya Smart |
| Voice Assistants | Amazon Alexa, Google Assistant |
| Control Methods | Touch panel + Mobile app |
| Frame Material | Aluminum |
| Panel Type | Deluxe flat touch panel |
| Neutral Wire | Required |
| Installation Type | Wall-mounted (standard switch box) |
| Smart Functions | Timers, Schedules, Scenes, Device Sharing |
| Application | Lighting & motorized curtains (indoor use) |
