TP-Link AXE5400 Tri-Band Gigabit Wi-Fi 6E Router | Archer AXE75

Archer AXE75 AXE5400 Tri-Band Gigabit Wi-Fi 6E Router

Description:

AXE5400 Tri-Band – AXE5400 Tri-Band Wi-Fi delivers Wi-Fi speeds up to 5400 Mbps.^†

Cutting-Edge Processing – Armed with a 1.7 GHz Quad-Core CPU.

SuperSpeed USB 3.0 – Up to 10× faster transfer speeds than USB 2.0.

Wi-Fi 6E Unleashed – The brand new 6 GHz band brings more bandwidth, faster speeds, and near-zero latency.

HomeShield – Customize your home network with enhanced security and control.*

OneMesh™ – Creates a Mesh network by connecting to a TP-Link OneMesh Extender for seamless whole-home coverage.

Connect More Devices—OFDMA technology increases capacity by 4 times to enable simultaneous transmission to more devices.^†

Ultra-Low Latency—Enables more responsive gaming and video chatting.

Compatible with Alexa—Control your router via voice commands and make your life smarter and easier with Amazon Alexa.

TP-Link Archer AXE75 – AXE5400 Tri-Band Wi-Fi 6E Router

Wireless

Standards & Protocols

◆ IEEE 802.11ax – 6 GHz
◆ IEEE 802.11ax/ac/n/a – 5 GHz
◆ IEEE 802.11ax/n/b/g – 2.4 GHz

Wi-Fi Speeds (AXE5400)

◆ 6 GHz: 2402 Mbps (802.11ax)
◆ 5 GHz: 2402 Mbps (802.11ax)
◆ 2.4 GHz: 574 Mbps (802.11ax)

Wi-Fi Range

◆ Ideal for 2–3 Bedroom Houses
◆ 6× Fixed High-Performance Antennas
◆ Beamforming
◆ High-Power FEM

Wi-Fi Capacity

◆ Very High
◆ Tri-Band Allocation
◆ OFDMA
◆ Airtime Fairness
◆ DFS
◆ 6 Streams

Working Modes

◆ Router Mode
◆ Access Point Mode

Security

Network Security

◆ SPI Firewall
◆ Access Control
◆ IP & MAC Binding
◆ Application Layer Gateway

HomeShield Security

◆ Real-Time IoT Protection
◆ Malicious Site Blocker
◆ Intrusion Prevention System
◆ DDoS Attack Prevention
◆ Home Network Scanner

Guest Networks

◆ 1× 6 GHz Guest Network
◆ 1× 5 GHz Guest Network
◆ 1× 2.4 GHz Guest Network

VPN

VPN Server: OpenVPN, PPTP, L2TP
VPN Client: OpenVPN, PPTP, L2TP

Wi-Fi Encryption

◆ WPA / WPA2 / WPA3
◆ WPA/WPA2-Enterprise (802.1x)

Hardware

Processor

◆ 1.7 GHz Quad-Core CPU

Ethernet Ports

◆ 1× Gigabit WAN
◆ 4× Gigabit LAN

USB

◆ 1× USB 3.0

Supported Formats: NTFS, exFAT, HFS+, FAT32
Supported Functions: Apple Time Machine, FTP Server, Media Server, Samba Server

Buttons

◆ Wi-Fi On/Off
◆ Power On/Off
◆ LED On/Off
◆ WPS
◆ Reset

◆ Power Supply: 12V ⎓ 2.5A

Software

Protocols

◆ IPv4
◆ IPv6

Service Kit

◆ HomeShield

OneMesh™

◆ OneMesh Supported

EasyMesh

◆ EasyMesh Compatible

Parental Controls (HomeShield)

◆ Custom Profiles
◆ Professional Content Filter Library
◆ Family Time / Bedtime / Off Time
◆ Time Rewards
◆ Online Time Ranking
◆ Pause Internet
◆ Weekly & Monthly Reports

WAN Types

◆ Dynamic IP
◆ Static IP
◆ PPPoE
◆ PPTP
◆ L2TP

QoS

◆ QoS by Device

Cloud Services

◆ Auto Firmware Upgrade
◆ TP-Link ID
◆ DDNS

NAT Forwarding

◆ Port Forwarding
◆ Port Triggering
◆ DMZ
◆ UPnP
◆ Virtual Server

IPTV

◆ IGMP Proxy
◆ IGMP Snooping
◆ Bridge
◆ Tag VLAN

DHCP

◆ Server
◆ Address Reservation
◆ DHCP Client List

DDNS

◆ TP-Link
◆ NO-IP
◆ DynDNS

Management

◆ Tether App
◆ Web Interface

Physical

◆ Dimensions: 272.5 × 147.2 × 49.2 mm
(10.7 × 5.8 × 1.9 in)

Environment

◆ Operating Temperature: 0°C to 40°C
◆ Operating Humidity: 10%–90% Non-Condensing

Certifications

◆ FCC
◆ RoHS

Package Contents

◆ Archer AXE75 Router
◆ Power Adapter
◆ RJ45 Ethernet Cable
◆ Quick Installation Guide
